| Model | Hammer Length without bit | Top sub thread | Outside diameter | Weight | Bit diameter | Working Pressure | Air consumption | Bit shank |
| 110P-2.8KW(Bayonet) | 662 (mm) | F72*10 BOX | 98 (mm) | 24 (KG) | 110-140 (mm) | 7-11 (Bar) | 7-12 (M3/min) | KNSH-110 |
| 110P-2.8KW(Spline) | 670 (mm) | F72*10 BOX | 98 (mm) | 25.5 (KG) | 110-140 (mm) | 7-11 (Bar) | 7-12 (M3/min) | KNSH-110 |
| 110P-3.2KW(Bayonet) | 672 (mm) | F72x10 BOX | 103x98 (mm) | 25.6 (KG) | 110-140 (mm) | 7-11 (Bar) | 7-12 (M3/min) | KNSH-110 |
| 110P-3.2KW(Spline) | 681 (mm) | F72*10 BOX | 103x98 (mm) | 26 (KG) | 110-140 (mm) | 7-11 (Bar) | 7-12 (M3/min) | KNSH-110 |
| 130P-4.0KW(Bayonet) | 655 (mm) | F72x10 BOX | 116 (mm) | 35.5 (KG) | 130-160 (mm) | 7-11 (Bar) | 7-12 (M3/min) | KNSH-130 |
| 130P-4.0KW(Spline) | 681 (mm) | F72x10 BOX | 116 (mm) | 36 (KG) | 130-160 (mm) | 7-11 (Bar) | 7-12 (M3/min) | KNSH-110 |
| 140P-4.5KW(Spline) | 728 (mm) | F72x10 BOX | 120 (mm) | 35.5 (KG) | 140-165 (mm) | 7-11 (Bar) | 7-12 (M3/min) | KNSH-140 |
